WS-9200/9250

WS-9200/9250 자동 휴대용 물 샘플러, 7000mL 용량의 산업용 등급 휴대용 물 샘플러로 시간/유량/레벨 비례 샘플링을 지원합니다. 냉장 보관(4±2°C), 자동 튜브 헹굼 및 IP55 보호 기능을 갖추고 있습니다. 환경 모니터링, 폐수 테스트 및 현장 연구에 이상적입니다. AC/DC 전원 및 외부 펌프와 호환됩니다.

Product Details

제품 세부정보

Contact Now

지금 연락하세요

제품 세부정보

제품 매개변수

샘플 병 24, 체육
샘플링 병 용량 1000mL
화면 인터페이스 7인치 컬러 터치스크린, 영어 인터페이스
시간이 지정된 샘플링 시점 24개의 프로그래밍 가능한 시점
외부 펌프 지연 1~9999분까지 1분 단위로 프로그래밍 가능
샘플링 간격 1~9999분까지 1분 단위로 프로그래밍 가능
단일 샘플링 볼륨 10~1000mL까지 1mL 단위로 프로그래밍 가능
혼합 샘플 수 1 ~ 50
복제 샘플 수 1 ~ 5
샘플링 볼륨 오류 ±5%
비례 샘플링 볼륨 오류 ±5%
펌프 튜브 유형 수입됨
냉동방식 압축 기계식 냉동
냉장 상자 온도 조절 정확도 (4±2)°C
수평 샘플링 거리 ≥80m
수직 샘플링 높이 ≥8m
파이프라인 기밀성 ≤-0.085MPa
아날로그 획득 오류 ±0.04mA
시스템 클럭 타이밍 오류 ≤5초/24시간
장비 작동 온도 -30°C ~ 40°C
작동 습도 85%RH 이하
절연저항 >20MΩ
Mean time between failures (MTBF) ≥1440h/주기
보호 등급 IP55
치수 약 711mm × 460mm × 571mm(L × W × H)
총 중량 약 27kg



기능 특징

다중 트리거 모드 시간 비례 샘플링, 날짜 주기 샘플링, 흐름 비례 샘플링, 레벨 비례 샘플링, 시간별 샘플링, 즉시 샘플링 및 우량계 트리거 샘플링(요일 설정 지원)
다양한 샘플링 방법: 병당 단일 샷 샘플링, 병당 다중 샷 샘플링, 한 번에 여러 병 샘플링;
물 샘플 냉동: 물 시료를 냉장 보관할 수 있는 냉장고를 갖추고 있습니다.
난방: 저온에서도 정상적인 작동을 보장하기 위해 냉장고와 샘플링 펌프 영역 모두 가열 모듈이 장착되어 있습니다.
환경.
온도 조절: 온도 상한 및 하한을 조정할 수 있어 냉장고 온도를 디지털 형식으로 실시간 표시합니다.
자동 파이프 헹굼: 샘플링하기 전에 미리 샘플링된 샘플러를 사용하여 파이프를 헹구십시오. 프로그래밍 가능한 헹굼 주기 횟수를 통해 오염을 방지하기 위해 물 샘플로 파이프를 자동으로 헹굽니다.
자동 파이프라인 배수: 샘플링 전후에 파이프에서 물을 자동으로 배출하여 침전과 막힘을 방지합니다. 배수 시간은 프로그래밍 가능하며 샘플링 헤드에는 막힘을 줄이기 위한 필터 또는 백이 포함되어 있습니다.
구경 측정: 프로그래밍 가능한 배수, 헹굼 및 샘플링 시간과 해당 샘플 용량;
비밀번호: 프로그램 수정을 방지하기 위해 설정할 수 있는 시스템 로그인 비밀번호를 사용할 수 있습니다. 비밀번호는 비활성화될 수 있습니다.
구성 요소 테스트: 샘플러가 정지된 동안 연동 펌프와 같은 구성 요소를 수동으로 제어하여 작동 상태를 확인합니다.
외부 펌프: 프로그래밍 가능한 시작 지연으로 외부 펌프를 지원합니다.
액세스 제어: 기계적으로 제어됩니다. 접근 통제는 안전한 사용을 보장합니다.
전원 차단 보호: 매개변수 설정, 시스템 시계 및 데이터 기록은 장치 전원을 껐다가 다시 켜도 손실되지 않습니다.
샘플링 기록 기능: 샘플링 시간, 샘플링 모드, 샘플링 양, 샘플링 방법, 샘플링 시간, 샘플링 결과를 포함한 샘플링 기록을 자동으로 저장하며 최소 5,000개 기록을 저장합니다.
알람 기록 기능: 알람 시간, 알람 정보 등 알람 기록을 자동으로 저장하며 최소 2,000개 기록이 저장됩니다.
샘플링 실패 경보 기능: 물 과부하 감지 기능이 있으며 센서 상태에 따라 샘플링 성공 또는 실패를 결정하고 샘플링 실패가 발생하면 샘플링 로그에 기록을 생성합니다.
시계 교정 기능: 시계 교정 페이지에 액세스하여 연도, 월, 일, 시, 분, 초를 포함한 샘플러 시스템 시간을 설정합니다.
유량 기록(유량계 설치 시): 시간에 따른 순간적, 누적적 흐름을 기록합니다.
통신 인터페이스: 외부 통신 인터페이스가 장착되어 있으며 기본 인터페이스 유형은 RS232입니다.
오버플로 방지: 시스템은 물 샘플 넘침을 방지하기 위해 총 샘플링 용량을 7000mL 이하로 제어합니다.
아날로그 입력: 4~20mA 아날로그 입력 1개가 장착되어 있습니다.
연동 펌프 수명 알림: 연동 펌프의 작동 시간을 설정할 수 있으며 수명이 다하면 펌프 튜브를 교체하라는 메시지가 표시됩니다.
다중 전원 공급 장치 옵션: 세 가지 전원 공급 장치 옵션을 지원합니다: AC 110V/AC 220V(50/60Hz) US 3핀 플러그, DC 12V 주석 도금(극성 표시) 전원 코드, 차량용 시가 라이터 플러그(DC 12V).



JIRS ​​자동 휴대용 채수기 시리즈 WS-9200/9250/WS-9300/9350의 응용 개요

        JIRS ​​자동 휴대용 물 시료 채취기 시리즈는 다양한 환경 및 산업 물 시료 채취 응용 분야에서 강력한 성능을 발휘하도록 설계되었습니다. 이 샘플러는 정확하고 안정적인 물 샘플 수집이 필요한 폐수 처리장, 환경 모니터링 기관, 산업 폐수 관리 및 연구 기관에 이상적입니다.

        시간 비례, 흐름 비례, 레벨 비례, 우량계 트리거 샘플링을 포함한 다양한 샘플링 모드를 갖춘 이 시리즈는 우수 유출 모니터링, 강 및 호수 품질 평가, 오염원 추적과 같은 복잡한 시나리오에 적응합니다. 냉동 시스템(4±2°C)은 생물학적 오염물질이나 휘발성 유기 화합물과 같은 민감한 매개변수에 대한 시료 무결성을 보장하는 반면, 가열 모듈은 극저온 환경(-30°C)에서도 작동할 수 있도록 해줍니다.

        통신 인터페이스(RS232/4-20mA)를 통해 SCADA 시스템 및 유량계와 통합할 수 있어 장기간 무인 모니터링에 적합합니다. 응용 분야는 다음과 같습니다.

        1. 도시 폐수 처리 규정 준수 샘플링

        2. 산업 배출 모니터링(화학, 제약, 광업)

        3. 유역 관리 및 수문학 연구

        4. 비상대응 및 유출방지 검증

        5. 장기간에 걸쳐 고주파 샘플링이 필요한 연구 프로젝트

        6. 이 샘플러는 실험실 수준의 정확성과 현장에서 바로 사용할 수 있는 견고성을 결합하여 현대 수질 관리를 위한 탁월한 다양성을 제공합니다.







연락하세요

당사 제품에 관심이 있으시면 여기에 정보를 남겨주시면 곧 연락드리겠습니다.

* 이름

* 이메일

핸드폰

*메시지

자주 묻는 질문

워터 샘플러에 대해 자주 묻는 질문 FAQ

자동 헹굼 기능은 어떻게 시료 간 교차 오염을 방지하나요?

Down Down

당사의 물 샘플러는 3단계 세척 과정을 특징으로 합니다: 증류수를 사용한 샘플 전 헹굼, 샘플 후 튜브 배출, UV 살균(옵션). 이를 통해 튜브에 잔여 입자나 미생물이 남지 않도록 보장하고 EPA 지침에 따라 99% 이상의 샘플 무결성을 유지합니다.

깊은 유정 응용 분야에서 샘플러가 달성할 수 있는 최대 수직 리프트는 얼마입니까?

Down Down

향상된 다이어프램 펌프가 장착된 당사의 산업용 샘플러는 샘플링 정확도를 저하시키지 않고 최대 9미터 깊이에서 물을 추출할 수 있습니다. 특허받은 사이펀 방지 시스템은 깊은 우물 작업 중 역류를 방지합니다.

정전이나 원격지에서도 샘플러를 작동할 수 있나요?

Down Down

예. 당사 장치는 3중 전원 이중화를 지원합니다. 1. 기본: 100-240V AC 2. 백업: 12V DC 차량/보트 호환성 3. 비상: 태양광 충전 옵션으로 8시간 배터리 백업

막힘 없이 고침전물 샘플링을 어떻게 처리합니까?

Down Down

우리는 각 샘플 후에 자동으로 세척을 역전시키는 자체 청소 흡입 필터와 막힘 방지 튜브 설계를 통합합니다. 이 시스템은 유지 관리 개입 없이 최대 2,000mg/L의 부유 물질을 처리합니다.

귀하의 샘플러는 국제 환경 모니터링에 대해 어떤 인증을 보유하고 있습니까?

Down Down

모든 장치는 다음 인증을 받았습니다. 1. ISO 5667-5:2023(수질 샘플링 2. EU/UK 시장용 CE/UKCA 3. EPA 40 CFR §136.3(미국 폐수 지침) 4. 침수 보호를 위한 IP68 등급
